W05 Calling SNPs

Author

Renee Catullo

Published

March 9, 2026

W05 VCF Filtering for SNP Quality Control

Learning outcomes

By the end of this session you should be able to:

  • explain how absolute sample size and sampling balance among populations influence SNP discovery and population genetic inference in ddRAD datasets

  • describe why SNP datasets generated from reduced-representation sequencing are conditional on the samples used during locus discovery and filtering

  • recognise why it is generally inappropriate to call SNPs on a large dataset and then subset individuals for analysis

  • outline the main steps of a Stacks workflow in Galaxy that produces a VCF file from ddRAD sequencing data

  • apply a stepwise filtering strategy to remove unreliable loci and individuals from a VCF file

  • convert a filtered SNP dataset into a genlight object for analysis with dartR and related population genetic tools

From raw sequencing data to analysis-ready SNP datasets

Population genomic analyses typically begin with raw sequencing reads, not SNPs. In reduced-representation approaches such as ddRAD, these reads must first be processed through a bioinformatic pipeline that identifies loci, discovers polymorphic sites, and assigns genotypes to individuals.

Pipelines such as Stacks perform several key steps: sequencing reads are filtered for quality, clustered into loci within individuals, matched across individuals to build a catalogue of homologous loci, and then scanned for polymorphic sites. The resulting variants and genotype calls are exported in Variant Call Format (VCF).

Although the VCF file contains detailed information about every variant detected, this raw output is rarely suitable for direct population genetic analysis. Many called genotypes may be unreliable due to insufficient sequencing depth, low genotype quality scores, paralogous loci, or allele balance issues. Individuals may also have excessive missing data, and the dataset may contain non-biallelic sites, invariant loci, or multiple SNPs from the same RAD fragment that violate assumptions of independence used by many downstream analyses.

The goal of this session is to introduce you to a systematic pipeline that addresses each of these issues. The pipeline takes a VCF file as input, applies a series of increasingly targeted filters, and ultimately produces a genlight object ready for use with dartR and related tools.

Why is study design so important?

Study design determines the biological information that can be recovered from a genomic dataset. Decisions made before sequencing, such as how many individuals are sampled and how those individuals are distributed across populations, influence both the SNPs that are discovered and the population genetic patterns that can be detected.

In reduced-representation approaches such as ddRAD, loci are discovered from the sequencing reads present in the dataset. This means that the final SNP catalogue depends on the individuals included in the analysis. Increasing the number of individuals generally reveals more polymorphisms and rare alleles, while uneven sampling across populations can bias SNP discovery and allele frequency estimates toward the most heavily sampled groups. As a result, both absolute sample size and sampling balance among populations can influence estimates of diversity, allele frequencies, and population structure.

Study design also determines how well the data will support the intended analyses. Small sample sizes reduce the precision of diversity estimates, while unbalanced sampling can distort measures of genetic differentiation or clustering. Because the SNP dataset itself is shaped by the individuals included during locus discovery and filtering, changes to the sample set later in the analysis can alter the properties of the dataset. Careful planning of sampling strategy is therefore a critical first step in producing reliable and interpretable population genomic results.

Why is filtering so important?

Poor quality SNPs can have dramatic effects on downstream analyses. Unfiltered paralogous loci inflate heterozygosity estimates, distort population structure, and bias relatedness calculations. Individuals with excessive missing data can create spurious clustering patterns in ordination analyses. Secondary SNPs on the same fragment violate the independence assumptions of many population genetic methods.

A careful, stepwise filtering approach ensures that the final dataset contains only high-confidence, independent SNP loci scored across a reliable set of individuals. This is the foundation upon which all subsequent analyses depend.

Introduction to Galaxy Australia

In this first section we will briefly introduce Galaxy, a web-based platform for running In this workshop we will use Galaxy, a web-based platform that allows bioinformatic workflows to be run through a graphical interface. Galaxy provides access to many commonly used genomic analysis tools, including pipelines for RADseq data, while automatically recording parameters, software versions, and analysis steps. This makes it easier to reproduce analyses and track how datasets were generated.

For the purposes of this session, Galaxy will be used as the platform that produced the VCF files we will analyse later in the workshop. We will briefly demonstrate how Galaxy histories and tool outputs are organised so that you can understand where the SNP dataset comes from and how the analysis steps are recorded.

If you are unfamiliar with Galaxy and would like a more detailed introduction to the interface, a short tutorial is available here:

Intro to Galaxy

SNP Calling

This tutorial explains the basic layout of Galaxy and how to upload data, run tools, and track results in your analysis history. It is provided as a reference for those who wish to explore the platform further.

Introduction to STACKS

In this section we will introduce the Stacks pipeline, which is one of the most widely used software packages for assembling RADseq and ddRAD data into loci and identifying SNPs. Stacks takes short-read sequencing data and reconstructs loci across individuals, identifies polymorphic sites, and exports genotype data for downstream analyses such as population genetics or phylogeography.

We will not run the pipeline during this workshop, but it is important to understand the main stages of the workflow and how decisions made during these steps relate to study design. This pipeline is fully available in Galaxy, removing both installation and computational limitations.

The Stacks pipeline proceeds through several major stages. First, raw reads are demultiplexed and cleaned. Next, reads within each individual are assembled into candidate loci. These loci are then compared across individuals to build a catalogue of loci shared among samples. Finally, loci from each individual are matched against this catalogue and genotypes are assigned at each polymorphic site.

Key components of the pipeline include:

process_radtags
Demultiplexes sequencing reads, removes low-quality reads, and assigns reads to individuals.

ustacks
Assembles reads within each individual into stacks representing candidate loci.

cstacks
Builds a catalogue of loci shared among individuals by comparing loci across samples.

sstacks
Matches loci from each individual back to the catalogue to determine the allelic state at each locus.

populations
Calculates population genetic statistics and exports data in formats such as VCF for downstream analysis.

Understanding these steps is important because several of them interact directly with study design. In particular, the catalogue-building stage (cstacks) determines which loci are considered homologous across individuals. The individuals included in this step therefore influence which loci enter the final dataset. Sampling decisions such as how many individuals to include from each population can affect locus sharing, SNP discovery, and downstream population genetic inference.

Students should therefore familiarise themselves with the structure of the Stacks pipeline and the purpose of each stage before working with SNP datasets generated from RADseq data.

Full documentation for the pipeline is available in the Stacks manual:

https://catchenlab.life.illinois.edu/stacks/manual/

The manual provides detailed explanations of each component of the workflow, the parameters used during locus assembly and catalogue construction, and the outputs generated at each stage.

From VCF to genlight: a stepwise filtering pipeline for SNP quality control

In this session we will learn how to take a VCF file produced by a SNP calling pipeline (e.g. from Galaxy or Stacks) and process it through a series of quality control and filtering steps to produce a clean, reliable set of SNPs stored in a genlight/dartR object. By the end of the session you should understand the rationale behind each filtering step, the order in which filters should be applied, and how to convert the final filtered dataset into a format suitable for downstream population genetic analyses.

Introduction

From raw SNP calls to analysis-ready data

SNP calling pipelines such as Stacks, GATK, or FreeBayes produce output in Variant Call Format (VCF). While VCF files contain all the information about every variant site detected, the raw output is rarely suitable for direct analysis. Many called genotypes will be of low quality due to insufficient sequencing depth, poor genotype quality scores, paralogous loci, or allele balance issues. Individuals may have excessive missing data, and the dataset may contain non-biallelic sites, invariant loci, or secondary SNPs on the same fragment that violate assumptions of independence.

The goal of this session is to walk through a systematic filtering pipeline that addresses each of these issues. The pipeline takes a VCF file as input, applies a series of increasingly targeted filters, and ultimately produces a genlight object ready for use with dartR and related tools.

Overview of the filtering pipeline

The pipeline follows a logical sequence of steps:

  1. Read and inspect the VCF file — Load the VCF and examine its structure, including the number of loci, individuals, and the format of genotype fields.

  2. Hard filtering — Remove genotypes with insufficient read depth or low genotype quality scores by converting them to missing data (NA).

  3. Heterozygosity filtering — Identify and remove loci with excessively high observed heterozygosity, which are likely paralogs rather than true polymorphic sites.

  4. Allele balance filtering — Remove heterozygous genotype calls where the ratio of reference to alternate allele reads falls outside an acceptable range.

  5. Maximum depth filtering — Remove loci where read depth is suspiciously high, again indicative of paralogous mapping.

  6. Missing data filtering by sample — Remove individuals with too much missing data.

  7. Biallelic and minor allele count filtering — Retain only biallelic sites and remove invariant loci.

  8. Missing data filtering by SNP — Remove loci with excessive missing data across samples.

  9. Conversion to genlight — Convert the filtered VCF to a genlight object and attach metadata including population assignments, coordinates, and allele information.

  10. Fragment identification and secondary SNP removal — Identify SNPs that fall on the same fragment and retain only one SNP per fragment.

  11. Reproducibility assessment — Use technical replicates to estimate genotyping error rates and filter loci with poor reproducibility.

  12. Duplicate removal — Remove technical replicate individuals, keeping only unique genotypes.

A note on this session

This session is different from others in the course. Because the pipeline begins with a VCF file output from Galaxy (or similar), and requires specific input files (VCF, metadata, technical replicate information), the code presented here will not run interactively. Instead, the session serves as a detailed, annotated walkthrough of each step. You should follow along with the code and commentary, understanding the purpose and logic of each filter, so that you can adapt the pipeline to your own data.

Prerequisites and background knowledge

To follow this session you should be familiar with the VCF file format and understand the basic structure of genotype calls, including fields such as read depth (DP), genotype quality (GQ), and allele depth (AD). You should also have a working knowledge of R and be comfortable with the dartRverse, particularly the genlight object structure and common dartR functions.

An understanding of common SNP quality issues — such as paralogy, allele dropout, and genotyping error — will help you appreciate why each filtering step is necessary and how the threshold values are chosen.

Session overview

This session walks through the complete VCF filtering pipeline in a series of annotated steps. There are no interactive exercises, but you should study each step carefully and consider how you would adapt the thresholds and decisions for your own dataset.

  • Step 1: Load the VCF and inspect its structure
  • Step 2: Hard filter on read depth and genotype quality
  • Step 3: Remove loci with excessive heterozygosity
  • Step 4: Apply allele balance filter
  • Step 5: Filter on maximum read depth
  • Step 6: Remove samples with excessive missing data
  • Step 7: Filter for biallelic sites and minor allele count
  • Step 8: Filter SNPs by missing data
  • Step 9: Convert to genlight and attach metadata
  • Step 10: Identify fragments and remove secondary SNPs
  • Step 11: Assess reproducibility using technical replicates
  • Step 12: Remove duplicate individuals and finalise the dataset

Setup

To run this pipeline on your own data, you will need the following packages installed and loaded. The SNPfiltR package provides the core filtering functions, vcfR handles VCF file input/output, and dartRverse provides the genlight object framework and downstream analysis tools.

library(rdiversity)
library(dartRverse)
library(dplyr)

Tutorial

Step 1: Load and inspect the VCF file

The first step is to set your working directory and define paths to your input files. You need two files: the VCF file containing your SNP calls, and a metadata CSV file (often called a strata file) that contains at minimum the columns: id, pop, lat, lon, and genotype.

setwd("~")

# path to your VCF file
input <- ".vcf"

# read in the metadata file
meta <- read.csv("strata.csv")
head(meta)

Now read in the VCF file using read.vcfR. This creates a vcfR object containing three slots: @meta (header information), @fix (fixed variant information such as chromosome, position, and alleles), and @gt (the genotype matrix).

# read in the VCF file
data <- read.vcfR(input)

# inspect the object
data

It is always worth inspecting the fixed fields and the genotype matrix to understand what your data looks like before filtering.

# look at the first 10 rows of fixed variant information
data@fix[1:10, 1:8]

# look at genotype fields for the first 10 loci and first 2 samples
data@gt[1:10, 1:2]

# check sample names
colnames(data@gt)

Step 2: Hard filtering on depth and genotype quality

The first quality filter converts genotypes to NA if they fall below minimum thresholds for read depth and genotype quality. Genotypes supported by very few reads are unreliable, and low genotype quality scores indicate uncertainty in the genotype call.

Here we set a minimum read depth of 8 and a minimum genotype quality of 20. These are relatively standard thresholds, but you may need to adjust them depending on your sequencing platform and expected coverage.

# hard filter: minimum depth of 8, minimum genotype quality of 20
data.1 <- hard_filter(vcfR = data, depth = 8, gq = 20)

data.1

The function reports the percentage of genotypes converted to NA for each criterion. If a very large proportion of genotypes fail these filters, it may indicate a problem with the sequencing run or the SNP calling parameters.

Step 3: Remove loci with excessive heterozygosity

Loci with very high observed heterozygosity across all samples are almost certainly not true single-copy polymorphic loci. Instead, they are likely the result of reads from paralogous regions being mapped to the same reference position. These loci need to be identified and removed.

We calculate the proportion of heterozygous genotype calls at each locus and remove any locus where heterozygosity exceeds a threshold (here set at 60%).

Note: If you have already filtered for observed heterozygosity in Stacks, this step may not be necessary. It is particularly important for VCF files produced by AGRF or similar service providers where paralog filtering has not been performed upstream.

# extract the genotype matrix
geno_matrix <- extract.gt(data.1, element = "GT")

# function to calculate heterozygosity per locus
calculate_heterozygosity_per_locus <- function(geno_vector) {
  valid_calls <- geno_vector[!is.na(geno_vector) & geno_vector != ""]
  heterozygous_calls <- sum(valid_calls == "0/1" | valid_calls == "1/0")
  total_calls <- length(valid_calls)

  if (total_calls > 0) {
    return(heterozygous_calls / total_calls)
  } else {
    return(NA)
  }
}

# apply across all loci
heterozygosity_rates <- apply(geno_matrix, 1, calculate_heterozygosity_per_locus)
hist(heterozygosity_rates)

Examine the histogram to understand the distribution of heterozygosity across loci. You should see a peak at low to moderate values, with a tail extending towards 1.0 that represents likely paralogs.

# set threshold and filter
threshold <- 0.6
loci_to_keep <- which(heterozygosity_rates < threshold)

data.1 <- data.1[loci_to_keep, ]
data.1

# clean up
rm(geno_matrix, heterozygosity_rates, loci_to_keep, threshold,
   calculate_heterozygosity_per_locus)

Step 4: Allele balance filtering

For heterozygous genotype calls, we expect roughly equal numbers of reads supporting the reference and alternate alleles. If the allele balance is strongly skewed (e.g. 95% reference, 5% alternate), the heterozygous call is unreliable and may reflect sequencing error or mapping artefacts.

The filter_allele_balance function converts heterozygous genotypes to NA if the allele ratio falls outside the specified range.

Note on AGRF data: If your VCF uses the BSDP tag instead of AD for allele depth, you will need to rename it before running this filter. The commented-out code below shows how to do this. Stacks data typically uses AD already.

# uncomment the following if your VCF uses BSDP instead of AD (e.g. AGRF data)
# gt_data <- data.1@gt
# gt_data_modified <- apply(gt_data, 2, function(x) gsub(":BSDP:", ":AD:", x))
# data.1@gt <- gt_data_modified
# rm(gt_data, gt_data_modified)

# apply allele balance filter
data.2 <- filter_allele_balance(data.1, min.ratio = 0.15, max.ratio = 0.85)

Step 5: Maximum depth filtering

Loci with unusually high read depth are often paralogs or repetitive regions where reads from multiple genomic locations pile up at a single reference position. The max_depth function helps identify an appropriate cutoff.

First, run the function without a cutoff to visualise the depth distribution, then apply a cutoff to remove the high-depth tail.

# visualise depth distribution to choose a cutoff
max_depth(data.2)

# apply maximum depth filter (may need to be done iteratively)
data.3 <- max_depth(data.2, maxdepth = 250)
data.4 <- max_depth(data.3, maxdepth = 150)

data.4

The appropriate cutoff will depend on your sequencing depth and organism. Look at the distribution and choose a value that removes the obvious high-depth tail without discarding too many loci.

Step 6: Remove samples with excessive missing data

After genotype-level filtering, some individuals may now have a very high proportion of missing data. These individuals contribute little useful information and can distort downstream analyses. We identify and remove them.

# visualise missing data by sample
miss <- missing_by_sample(vcfR = data.4)

# remove samples above the missing data cutoff
data.5 <- missing_by_sample(vcfR = data.4, cutoff = 0.60)

After removing individuals from the VCF, we must also update the metadata file to keep it in sync.

# identify which samples were removed
names1 <- colnames(extract.gt(data.4))
names2 <- colnames(extract.gt(data.5))
lost <- setdiff(names1, names2)

# remove them from the metadata
meta <- meta[!(meta$id %in% lost), ]
rm(names1, names2, lost)

Step 7: Biallelic sites and minor allele count filtering

Many downstream analyses assume biallelic loci. We remove any multiallelic sites (this will have no effect on Stacks data, which only calls biallelic SNPs). We also remove invariant sites — loci that have become monomorphic after the sample and genotype filtering above.

# remove non-biallelic sites
data.5a <- filter_biallelic(data.5)

# remove invariant sites (minor allele count < 1)
data.6 <- min_mac(data.5a, min.mac = 1)

Step 8: Filter SNPs by missing data

Now we examine missing data from the perspective of each SNP. Loci with too much missing data across samples should be removed.

First, visualise the distribution to choose an appropriate threshold, then optionally assess how different missingness cutoffs affect PCA-based clustering.

# visualise missing data per SNP
missing_by_snp(data.6)

# assess effect of missingness thresholds on PCA clustering
assess_missing_data_pca(vcfR = data.6, popmap = meta[, c(1, 2)],
                        thresholds = c(0.8), clustering = FALSE)
# apply the chosen missing data threshold
data.7 <- missing_by_snp(data.6, cutoff = 0.6)

data.7

At this point it is good practice to save the filtered VCF as a checkpoint.

# save filtered VCF
write.vcf(data.7, file = "data7.vcf")

Step 9: Convert to genlight and attach metadata

The filtered VCF is now ready to be converted into a genlight object, which is the standard format used by dartR. During conversion, allele identity information (REF/ALT) is lost, so we save it beforehand and re-attach it afterwards.

Save allele information

# save allele information before conversion
alleles_info <- data.frame(
  CHROM = data.7@fix[, "CHROM"],
  POS   = data.7@fix[, "POS"],
  ID    = data.7@fix[, "ID"],
  REF   = data.7@fix[, "REF"],
  ALT   = data.7@fix[, "ALT"],
  row.names = NULL
)
Identify fragments for secondary SNP removal

When multiple SNPs occur on the same short DNA fragment (e.g. within a 63 bp read), they are not independent. We need to identify which SNPs belong to the same fragment so we can later retain only one SNP per fragment.

The following code creates a fragment identifier for each locus by examining the chromosome, the SNP ID prefix (which encodes the fragment group in Stacks output), and the physical position.

# extract fragment group from the SNP ID
alleles_info$frag_group <- as.integer(sub(":.*", "", alleles_info$ID))
alleles_info$POS <- as.numeric(alleles_info$POS)

# sort by chromosome, fragment group, and position
alleles_info <- alleles_info[order(alleles_info$CHROM,
                                    alleles_info$frag_group,
                                    alleles_info$POS), ]

# create an empty column for fragment ID
alleles_info$fragment_id <- NA

The assign_fragments function checks whether SNPs share the same chromosome and SNP ID prefix, and whether they are within 63 bp of each other (i.e. on the same sequenced fragment).

assign_fragments <- function(subdf, keys) {
  if (nrow(subdf) == 0) return(subdf)

  subdf$POS <- as.numeric(subdf$POS)
  n <- nrow(subdf)

  if (n == 1) {
    frag_id <- paste0(keys$CHROM, "_", subdf$POS[1], "_", keys$frag_group)
    subdf$fragment_id <- frag_id
    return(subdf)
  }

  positions <- subdf$POS
  group_ids <- integer(n)
  group_id <- 1
  current_group <- c(1)

  for (i in 2:n) {
    if (any(abs(positions[i] - positions[current_group]) <= 63)) {
      current_group <- c(current_group, i)
    } else {
      group_ids[current_group] <- group_id
      group_id <- group_id + 1
      current_group <- c(i)
    }
  }
  group_ids[current_group] <- group_id

  subdf$fragment_id <- NA_character_
  for (gid in unique(group_ids)) {
    idx <- which(group_ids == gid)
    min_pos <- min(subdf$POS[idx])
    frag_id <- paste0(keys$CHROM, "_", min_pos, "_", keys$frag_group)
    subdf$fragment_id[idx] <- frag_id
  }

  return(subdf)
}

# apply fragment assignment
alleles_info <- alleles_info %>%
  group_by(CHROM, frag_group) %>%
  group_modify(~ assign_fragments(.x, .y)) %>%
  ungroup()

# create a SNP label for later use
alleles_info$SNP <- paste0(alleles_info$POS, ":", alleles_info$REF, ">", alleles_info$ALT)
Convert to genlight
# convert VCF to genlight
gl.1 <- vcfR2genlight(data.7)

# assign individual names from metadata
indNames(gl.1) <- meta$id
Inspect clustering with a dendrogram

Before proceeding, it is useful to check that technical replicates cluster together, which confirms that the genotyping is consistent.

# assess dendrogram-based clustering
dist <- gl.dist.ind(gl.1)
hc <- hclust(dist)
plot(hc)
Attach metadata to the genlight object
# set ploidy
ploidy(gl.1) <- 2

# attach individual metadata
gl.1@other$ind.metrics <- meta[, c(1:ncol(meta))]

# assign populations
gl.1 <- gl.reassign.pop(gl.1, as.pop = "pop")
table(pop(gl.1))

# run compliance check and recalculate locus metrics
gl.1 <- gl.compliance.check(gl.1)
gl.1 <- gl.recalc.metrics(gl.1)
head(gl.1@other$loc.metrics)

# add allele information back to locus metrics
gl.1@other$loc.metrics$SNP <- alleles_info$SNP
gl.1@other$loc.metrics$CloneID <- alleles_info$fragment_id

# assign lat/long coordinates
gl.1@other$latlong <- gl.1@other$ind.metrics[, c(3:4)]

# check the mapping
gl.map.interactive(gl.1)

Step 10: Assess reproducibility using technical replicates

Technical replicates (the same individual genotyped more than once) allow us to estimate the genotyping error rate at each locus. Loci with poor reproducibility between replicates should be removed, as genotyping errors at these loci will introduce noise into any analysis.

Load replicate information

You need a CSV file (techreps.csv) with no header, where the first column is the sample name as it appears in the genlight, and the second column is an identifier that links replicates of the same individual.

# read technical replicate information
reps <- as.data.frame(read.csv(file = "techreps.csv", header = FALSE))

# subset to replicates present in the genlight
reps <- reps[reps$V1 %in% indNames(gl.1), ]
Calculate reproducibility

The following code compares genotype calls between pairs of technical replicates at every locus, counting mismatches as errors.

# extract genotype matrix and transpose
geno <- as.data.frame(t(as.matrix(gl.1[, ])))
geno[1:10, 1:10]

# subset to replicate samples only
gt_reps <- as.data.frame(geno[, colnames(geno) %in% reps$V1])

# initialise mismatch tracking matrix
snp.tech.match.rd <- matrix(NA, nrow = nrow(gt_reps), ncol = ncol(gt_reps))
colnames(snp.tech.match.rd) <- colnames(gt_reps)

# get unique duplicate groups
duplicate_groups <- unique(reps$V2)

# compare replicates within each group
for (group in duplicate_groups) {
  cols <- which(colnames(gt_reps) %in% reps$V1[reps$V2 == group])

  if (length(cols) == 2) {
    for (r in 1:nrow(gt_reps)) {
      if (!is.na(gt_reps[r, cols[1]]) && !is.na(gt_reps[r, cols[2]])) {
        if (gt_reps[r, cols[1]] != gt_reps[r, cols[2]]) {
          snp.tech.match.rd[r, cols[1]] <- "ERROR"
          snp.tech.match.rd[r, cols[2]] <- "ERROR"
        } else {
          snp.tech.match.rd[r, cols[1]] <- "MATCH"
          snp.tech.match.rd[r, cols[2]] <- "MATCH"
        }
      }
    }
  }
}

snp.tech.match.rd <- as.data.frame(snp.tech.match.rd)
Calculate and visualise reproducibility scores
# count errors per SNP
snp.tech.match.rd$error <- apply(snp.tech.match.rd[, -1], 1, function(row) {
  sum(row == "ERROR", na.rm = TRUE) / 2
})

# calculate reproducibility as a proportion
snp.tech.match.rd$reproducibility <- 100 -
  ((snp.tech.match.rd$error / ((ncol(snp.tech.match.rd) - 1) / 2)) * 100)
snp.tech.match.rd$reproducibility <- snp.tech.match.rd$reproducibility / 100

# plot reproducibility distribution
hist(snp.tech.match.rd$reproducibility,
     main = "Reproducibility between technical replicates (pairs)",
     cex.main = 0.8, xlab = "Reproducibility %")
Attach reproducibility to genlight and filter
# verify locus name order matches between VCF and genlight
fix <- as.data.frame(data.7@fix)
LOC_Names <- as.data.frame(paste(fix$CHROM, fix$POS, sep = "_"))
all(fix$ID == gl.1@loc.names)  # should be TRUE

# save a backup
gl_store <- gl.1

# attach reproducibility to loc.metrics
loc.metrics <- as.data.frame(cbind(data.7@fix[, c(1:8)],
                                    snp.tech.match.rd$reproducibility))
names(loc.metrics)[9] <- "Reproducibility"
gl.1@other$loc.metrics <- cbind(gl.1@other$loc.metrics, loc.metrics)

gl.1@other$loc.metrics$Reproducibility <-
  as.numeric(gl.1@other$loc.metrics$Reproducibility)

# visualise and filter on reproducibility
hist(gl.1@other$loc.metrics$Reproducibility,
     col = 'skyblue3', breaks = 20, xlab = NULL,
     main = "Locus Reproducibility PREFILT")

rp <- 0.97
gl.1 <- gl.1[, which(gl.1@other$loc.metrics$Reproducibility > rp)]
gl.1@other$loc.metrics <-
  gl.1@other$loc.metrics[which(gl.1@other$loc.metrics$Reproducibility > rp), ]
gl.1 <- gl.recalc.metrics(gl.1, verbose = 0)
min(gl.1@other$loc.metrics$Reproducibility)
Quick PCA check

After reproducibility filtering, it is good practice to run a quick PCA to see how the data is looking.

pc <- gl.pcoa(gl.1)
barplot(pc$eig / sum(pc$eig) * 100)
gl.pcoa.plot(pc, gl.1, pop.labels = "pop", xaxis = 1, yaxis = 2)

Step 11: Remove duplicate individuals

Technical replicates were needed to assess reproducibility, but they must be removed before analysis to avoid pseudoreplication. We keep only one representative per unique genotype.

# identify unique individuals
df <- as.data.frame(gl.1@other$ind.metrics)
unique <- df[!duplicated(df$genotype), ]
unique_names <- unique$id

# keep only unique individuals
gl.1 <- gl.keep.ind(gl.1, unique_names, recalc = TRUE, mono.rm = TRUE)
dim(gl.1)

# rename individuals to their genotype ID
indNames(gl.1) <- gl.1@other$ind.metrics$genotype

Step 12: Remove secondary SNPs

The final step is to ensure that only one SNP per fragment is retained. Multiple SNPs on the same fragment are not independent and can bias analyses that assume linkage equilibrium among loci.

We use the fragment IDs assigned earlier to identify groups of linked SNPs and keep only the first SNP from each group.

# get fragment IDs
clone_ids <- gl.1@other$loc.metrics$CloneID

# keep only the first SNP per fragment
keep_loci <- !duplicated(clone_ids)

gl.1 <- gl.1[, keep_loci]
gl.1@other$loc.metrics <- gl.1@other$loc.metrics[keep_loci, ]
Final PCA check
pc <- gl.pcoa(gl.1)
barplot(pc$eig / sum(pc$eig) * 100)
gl.pcoa.plot(pc, gl.1, pop.labels = "pop", xaxis = 1, yaxis = 2)

Step 13: Save the final genlight object

The filtered genlight object now contains depth-filtered, reproducibility-checked, independent SNP loci scored across unique individuals with all relevant metadata attached. This object can be used directly for phylogenetic or population genetic analyses.

# clean up intermediate objects
rm(data, data.1, data.2, data.3, data.4, data.5, data.6, data.7,
   geno, gl_store, gt_reps, hc, loc.metrics, meta, miss, pc, reps,
   snp.tech.match.rd, dist, input, rp, unique_names, fix, LOC_Names,
   data.5a, alleles_info, df, unique, duplicate_groups, group,
   assign_fragments, clone_ids, keep_loci)

# save the final workspace
save.image("gl_1.Rdata")

Additional reading

  • O’Leary, S. J., et al. (2018). These aren’t the loci you’re looking for: Principles of effective SNP filtering for molecular ecologists. Molecular Ecology, 27(16), 3193–3206.
  • The SNPfiltR package documentation and vignettes.
  • The dartRverse website and tutorials for downstream analysis options.

Winding up

Discussion Time

Consider the following questions for group discussion:

  • How would you decide on appropriate threshold values for each filter step when working with a new dataset?
  • What are the consequences of filtering too aggressively versus too leniently?
  • How does the order of filtering steps matter? Would the results change if you applied the filters in a different sequence?
  • What would you do differently if you did not have technical replicates available?

Where have we come?

In this session we have walked through a complete pipeline for converting raw VCF output into a clean, analysis-ready genlight object. You have seen how to apply hard filters on depth and genotype quality, remove paralogous loci using heterozygosity and depth filters, apply allele balance checks, handle missing data at both the sample and locus level, assess and filter on reproducibility using technical replicates, remove duplicate individuals, and retain only independent SNPs by filtering secondary SNPs on the same fragment. This filtered dataset forms the foundation for all subsequent population genetic and phylogenetic analyses in the dartRverse.
